TensorFlow Lite for Microcontrollers (TFLM) is the part of the TensorFlow ecosystem that runs on devices with no operating system, no dynamic memory allocator you would trust, and often less than 512 KB of RAM. It is not a stripped-down version of the full runtime; it is a separate C++ library designed from scratch for bare-metal and RTOS environments. If you have a development board sitting in a drawer, this is a good weekend project.

The workflow has four steps: train a small model, convert it to a TensorFlow Lite flatbuffer, convert that flatbuffer into a C array, and link it into your firmware. The training part can happen on your laptop with normal TensorFlow. Everything after that is about making the model fit and run on the target.

Choosing Hardware and Setting Up the Toolchain

You do not need anything exotic. An STM32 Nucleo board, an Arduino Nano 33 BLE Sense, an ESP32, or a Raspberry Pi Pico will all work. The Pico is a popular choice because it is cheap, well documented, and has enough RAM for small models. The Nano 33 BLE Sense is nice if you want built-in sensors, since you can feed accelerometer or microphone data directly into the model without wiring anything extra.

Install the Arduino IDE or the PlatformIO extension for VS Code, then pull in the TensorFlow Lite for Microcontrollers library. On Arduino, this is available through the library manager. On PlatformIO, you add it to your platformio.ini. You will also need a way to generate the C array from your .tflite file. The standard tool is xxd, which is available on Linux and macOS and can be installed on Windows through Git Bash or WSL. A common command looks like xxd -i model.tflite > model_data.cc, which produces a byte array you can include in your sketch.

Keep an eye on the size of that array. A 100 KB model becomes a 100 KB array in your source, and that has to fit in flash. If your board has 1 MB of flash, you have room, but you also need space for the runtime and your application code.

Writing the Inference Loop

The TFLM API is small. You create an interpreter, give it an op resolver, point it at your model array, and allocate a tensor arena. The tensor arena is a single block of memory that the interpreter uses for all intermediate tensors. Getting its size right is the most common source of frustration. Too small and initialization fails; too large and you waste RAM. A reasonable starting point is a few tens of kilobytes, then adjust based on the error message.

Once the interpreter is initialized, inference is a three-step cycle: copy input data into the input tensor, call Invoke(), read the output tensor. That is it. The model does not know or care that it is running on a microcontroller. If you trained a keyword spotter, you feed it a window of audio samples and read out class scores. If you trained a gesture classifier, you feed it accelerometer readings.

The main practical challenges are input preprocessing and timing. Microphone input needs to be windowed and converted to the same feature representation you used during training, usually MFCCs, and that preprocessing code often takes more effort than the inference itself. Timing matters too, because you need the whole loop, sampling, preprocessing, inference, and any output, to finish before the next window arrives.

Start with a model you already know works on your laptop. Port it to the board without changing anything except the input source. Get one correct prediction, then optimize. The first working inference on a microcontroller is a genuinely satisfying moment, and after that the rest is iteration.
